SERVER BASED UC PLATFORM

2-3 Days SERVER BASED UC PLATFORM

ANANT UNIFIED COMMUNICATION SOFTWARE

Traditional hardware based PBXs are slowly getting replaced by open server based telephony systems. This is largely because hardware based PBXs create hardware dependency, require manual upgradation and incur heavy wiring cost. Matrix has designed an enterprise-grade highly capable, durable, scalable and efficient Unified Communication Software solution – ANANT UCS. The hardware-independent platform provides customers with a choice to select a reliable server as per their requirement. With a range of enterprise grade calling features, it improves employees’ productivity and speeds up the decision-making process.

ANANT UCS connects all the employees on a single platform. The employees can connect from anywhere at any time by installing Matrix VARTA on Laptops /Tablets /PCs /Smartphones devices of their choice. Our UC Server offers a range of enterprise grade calling features that improves employees’ productivity and speeds up the decision making process. With an in-call redundant system, ANANT UCS boasts of providing the best customer engagement. By integrating ANANT with VoIP Gateways and IP Phones, customer requirements with multiple location communication set-up can be met.





TECHNICAL SPECIFICATIONS

ParameterDetails
SIP Extensions5000
SIP Trunks99
Maximum Transcoding Audio Calls (a-Law/u-Law)Based on Resources (Max. 1024)
Maximum Transcoding Audio Calls (G.729Based on Resources (Max. 1024)
Maximum DRTP/RTP Relay Audio Calls1024
Maximum DRTP/RTP Relay Video Calls102
Maximum Voicemail Channels64
Maximum Conference Participants (System wide)1536
Maximum 3-Party Conference512
Maximum Participants in a Single Multi-Party or Dial-In Conference64
Maximum Call Tapping or Recordings64
Audio CodecsG.729, G.711(A-law, μ-law), G.722, iLBC (30 ms, 20 ms)
Supported IETF RFCs3261, 3262, 3389, 3550, 3551, 3311, 3265, 4733, 2915, 2916, 2327, 2833, 2806, 768, 793, 1034
Network ProtocolsIPv6, IPv4, TCP, UDP, SNTP, ARP, ICMP, PPP, DNS, SMTP, STUN
VoIP Quality of ServiceSupport of Layer 2/3 CoS/QoS for SIP Support of Layer 3 QoS for RTP
SecuritySRTP/TLS over SIP, MD5 Authentication for SIP, Password encrypted with AES128 algorithm
ConfigurationWeb Based Intuitive GUI, Jeeves

SERVER SPECIFICATIONS

ParameterDetails
Server ModelAny
Processor ModelIntel Xeon E-2134 or above
CPU Speed3.5 GHz or above
CPU Core/Thread4/8
Max Turbo Frequency4.5 GHz or above
Cache8 MB Smart Cache
RAM8 GB DDR4 ECC
Hard Disk1 TB (1 No.) - Without RAID Support
1 TB (2 Nos.) - With RAID1 Support
1 TB (3 Nos.) - With RAID5 Support
Form Factor1U (RACK)
Raid Controller (Optional)H330 Raid Controller*

*Note: H330 Raid Controller is built-in hardware in Dell Server.

CENTRALIZED HYBRID DEPLOYMENT

ANANT Centralized Hybrid Deployment



CENTRALIZED IP DEPLOYMENT

ANANT Centralized IP Deployment
